R5905948 /12 Event Master Devices 367
Image 12-5
The 12 Contextual Buttons to the left of the numpad are used to add situational functionality to the syntax.
Certain button presses change the naming of the displays and the functions of the buttons. They are referred
to as CD1 thru 12 per row from the top left.
General rules
Note that all possible syntax is not supported.
A few general rules:
• Any Syntax entry must end with ENTER.
• Any Syntax is max 3 Functions deep before ENTER.
• In the case of unsupported syntax it will just not work or register.
The Syntax Feedback line in the Controller Menu Page is a huge help to understand what is
supported and not.
12.13 Function Button For Syntax
Destination
Image 12-6
Destination refers to the most downstream location in the chain, usually a screen. See the earlier Chapters for
the definition of Destination.
When DEST is pressed it lights its blue LED and opens the syntax entry for numbers and modifiers as per
above.
The contextual Buttons to the right of the numpad also light up and is populated with functionality that can be
used in the syntax. These are:
Contextual
Button
Display Description
CD1 AUX
• DEST + AUX # ENTER select the Aux #, just as clicking it in the GUI.
• DEST + AUX 1 + 2 + 5 ENTER will select Aux 1, 2, and 5.
• DEST + AUX - 2 ENTER will unselect Aux 2, but 1 and 5 stays selected
CD2 BG Input 0 is Matte and maps the WH1 Red, WH2 Green, WH 3 Blue
CD3 Group
• DEST + Group # ENTER arms the Destinations in that particular group,
just like clicking it in the GUI.
• DEST + Group 1 + 3 + 5 ENTER arms Destination Groups 1, 3, and 5.
• DEST + Group − 3 ENTER disarms Destinations in Group 3 while
leaving destinations in Groups 1 and 5 armed.
CD4 Super Dest
• DEST + Super Dest # ENTER arms that particular Super Destination
(including the destinations that compose it).
• DEST + Super Dest 1 + 2 + 4 ENTER arms Super Destinations 1, 2,
and 4.
Controller Operation
