R5905948 /12 Event Master Devices538
• WebUI
• Ethernet RJ-45, 1000/100/10 Mbps autosense
Serviceability
• Field-serviceable I/O and processing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies
Noise level Max 52.9 dB avg. Fans at 100%. Fan speed is software-managed based
on operating temperature. Reference ISO 7779.
Dimensions
• Height: 17.8 cm (7.0 in) – 4 RU rackmount
• Width: 43.2 cm (17 in) without chassis handles, 48.3 cm (19 in) with
chassis handles attached
• Depth: 56.9 cm (22.4 in) from front panel to rear panel, 62.2 cm (24.5 in)
overall
Weight 31 kg / 68 lbs
Power
• Input power: 100–240 VAC 50/60Hz 826W
• Ships with dual-redundant, hot-swappable power supplies
Warranty 3 years parts and labor
Environmental temperature 0–40° C / 32–104° F
Environmental humidity 0–95% non-condensing
A.4 Specifications of S3–4K
R9004757 – S3–4K Specifications
Model NGS-3U / NGS-3U BTO
Live effects canvas
• Up to 20 Megapixels PVW/PGM
• 40 Megapixels PGM only
Video inputs 12 HD inputs via 3 input cards (Event Master Series 1 cards)
• Up to 3 x 4K inputs – each input card supports up to 1 x 4K@60p
• 4 x SD/HD/3G SDI
• 4 x HDMI 1.4a (297 Mpix/sec max)
• 4 x DisplayPort 1.1 (300 Mpix/sec max)
Video outputs 12 HD outputs via 3 output cards (Event Master Series 1 cards)
• Up to 3 x 4K outputs – each output card supports up to 1 x 4K@60p
• 4 x SD/HD/3G SDI – 4 x HDMI 1.4a (297 Mpix/sec max)
• 4 x HDMI 1.4a (297 Mpix/sec max)
• 2 x HDMI 1.4a for Multiviewer (297 Mpix/sec max)
(4 x HDMI 1.4a when used as standard output card)
Genlock Analog reference input/loop on BNC connectors; bi-level and blackburst at
SD and tri-level at HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output 8 program outputs configurable as single screens or tiled/blended
widescreens
• Configurable from 8 x 2048X1200@60 max to 2 x 4096x2400@60 max
• Independent edge blending/feathering control for all four sides
Program scaling (PiP/Key)
layers
• Native resolution background mixer per output screen
• Independent layer transitions or full Preview/Program transition
• Flexible layer allocation – 4 mixable or 8 single scalable PIP/key layers
assignable to any Program output screen
Scaled Aux outputs
• User definable from 8 x 2048x1200@60 to 2 x 4K@60
Specifications
