Barco Event Master E2 Series User Manual

R5905948 /12 Event Master Devices 537
Video inputs 40 inputs via 8 input cards (Event Master Series 2 cards)
• Up to 16 x 4K inputs or up to 40 HD inputs – each input card supports
up to 2 x 4K@60p
• 16 x SD/HD/3G/6G/12G SDI connectors
• 12 x HDMI 2.0 (600 MHz max)
• 12 x DisplayPort 1.2 (660 MHz max)
Video outputs 18 output connectors among 4 output cards (Event Master series 2 cards)
• Up to 8 x 4K outputs (depending on configuration) – each output card
supports up to 2 x 4K@60p
• 4 x SDI (SD/HD/3G/6G/12G)
• 13 x HDMI 2.0 (up to 600 MHz)
• 1 x DisplayPort 1.2 (up to 660 MHz)
NO MVR: Up to 8 x 4K60p outputs
WITH MVR: Up to 6x 4K60p outputs and either 4x HDMI for FHD
Multiviewers (1920x1200 max) OR 1x HDMI for UHD/4K60p Multi-viewer
Genlock Analog reference input/loop on BNC connectors; bi-level and blackburst at
SD and tri-level at HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output Up to 16 program outputs configurable as single screens or tiled/blended
widescreens (preview and Multiviewer not available in all configurations)
• Configurable for up to 16 x 2048X1200@60 or up to 8 x 4096x2400@60
• Independent edge blending/feathering control for all four sides
Program scaling (PiP/Key)
layers
• Native resolution background mixer per output screen
• Independent layer transitions or full Preview/Program transition
• Flexible layer allocation – 16 mixable or 32 single scalable PIP/key
layers assignable to any Program output screen
Scaled Aux outputs
• User definable for up to 18 x 2048x1200@60 or up to 8 x 4K@60
• All outputs can be defined as Aux destinations for a total of 18 Aux
outputs
• Output color correction
(Preview and Multiviewer not available in all configurations.)
Still stores Up to 100 HD or 25 UHD, depending on the import file size.
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma, chroma and Cut/Fill keys (not all modes support keying)
• PIP moves via Keyframes
Multiviewer
• Flexible user-definable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
• Dedicated hardware same as E2 Event Master processors
Expandability
• Easily expandable for larger display applications via non-proprietary
links
• Link units to increase available Inputs and Outputs for larger tiled/
blended widescreen applications
• Expansion via simple linking – up to 8 chassis
• E2 ships with the ability to link 8 chassis for expansion.
HDCP HDCP compliance determined by installed cards.
Control
• Event Master screen management software for PC or MAC
• Event Master controllers
