R5905948 /12 Event Master Devices 75
Specifications
• Supported format:
Signal
type
Min. BNC
connector
number
Max
channels
per card
Standard Examples
SD 1 4 SMPTE 259M-C 480i, 576i (NTSC/PAL)
HD 1 4 SMPTE 292M 1920x1080 @ 59.94i/50i
1920x1080psf @ 23.98/24/25/29.97/30
720x480 @ 60p/50p
3G 1 4 SMPTE 424M
Barcolink
1920x1080 @ 60p/50p
1920x1200 @ 60p/50p
4K / UHD 4 1 SMPTE 292M
SMPTE 2048-2
Image mapping: Quadrants
3840x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4096x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4K / UHD 4 1 SMPTE 424M
SMPTE 2048-2
Image mapping: Quadrants
3840x2160 @ 50/59.94/60 as 4x 3G-SDI
4096x2160 @ 50/59.94/60 60 as 4x 3G-SDI
Level A and B supported
4K / UHD 4 1 SMPTE ST 425-5 Image mapping: 2 Sample Interleave
Subdivision (2SI)
3840x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4096x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
3840x2160 @ 50/59.94/60 as 4x 3G-SDI
4096x2160 @ 50/59.94/60 60 as 4x 3G-SDI
Level A and B supported
SDI
Serial Digital Interface (SDI) is a serial link standardized by the Society of Motion Picture and
Television Engineers (SMPTE). SDI transmits uncompressed digital video over 75-ohm coaxial
cable within studios, and is seen on most professional video infrastructure equipment.
4.13 Tri-Combo Output Card
General
This card provides one 20-pin DisplayPort connector, supporting DisplayPort video signal; one 19-pin HDMI
connector, supporting an HDMI video signal; and 4 BNC connectors, supporting Single Link, Dual Link, and
Quad Link signals, in SD, HD, 3G, 6G, and 12G SDI formats.
The figure below illustrates the tri-combo output card’s rear panel connectors:
Hardware orientation
