17.1 Servicing
General
The EC-30 controller has no user-serviceable parts.
In the unlikely event your EC series controller requires service, please refer to the Return Material
Authorization section in this manual prior to sending the unit back to the Barco Service Department.
EC-30 Overview
Orientation and main components
Front:
Image 17-1: EC-30 controller (Front view)
1 Keyboard
2 T-bar
3 25W, 12V power supply brick
Rear:
Image 17-2: EC-30 controller (Rear view)
1 T-bar
2 Strain-relief tabs
3 USB B to Host
4 DC power
5 25W, 12V power supply brick
EC-30 Maintenance
To Next Page
