R5905948 /12 Event Master Devices 133
Input adjustment panel > Color Adjustment
This menu allows for color adjustments for each input.
• The RGB Contrast and Brightness settings are
adjustable.
- The Overall adjustment has a range of 50 to
150.
- The individual Red/Green/Blue adjustments
have a range of 25 to 150.
- The default setting for all of these properties is
100.
• Gamma is adjustable within a range of 0.31 to
3.29. The default setting is 1.0.
• Hue is adjustable within a range of –90 to +90
degrees. The default setting is 0 degrees.
• Saturation is adjustable within a range of 0 to 150.
The default setting is 100.
• Reset All changes all values to their default
settings.
Input adjustment panel > Contact Information
This menu allows for the user to enter contact information for easy identification.
6.14 Configuration Menu > Adjustment >
Background Configuration
General
Assigning input connectors to backgrounds is very similar to creating Inputs as it was discussed in the
previous section. Therefore, the menus are also very similar and for the sake of simplicity the same menus are
not going to be presented in this section.
EM GUI orientation
