- Added support for E2-Gen2 video processor. Refer to “Event Master devices
overview”, page 26, and see the “About E2 Gen 2” subsection.
- Added support for 4K Quad HDMI 2.0 Output card as a Multiviewer.
- Added CXP Input/Output card. Refer to “CXP Input/Output Card”, page 79.
1.3 Symbols, pictures and fonts
Symbol overview
The following icons are used in the manual :
Caution
Warning
Info, term definition. General info about the term
Note: gives extra information about the described subject
Tip: gives extra advice about the described subject
Picture overview
Images and pictures given in the manual are used as illustration. The content of the images can be slightly
different with the reality, e.g. version numbers, device types, installed modules, form and position of software
windows on screen ...
1.4 The 4K screen management system
The presentation systems E2 and S3–4K
Raising the bar for live screen management, the Event Master screen management system provides superior
image quality, exceptional input and output density, great expandability, and purpose built durability.
Supporting native 4K input and output with up to 60 Hz refresh rates and 4:4:4 color, it is the most modular
system available to manage blended 4K projectors with refresh rates up to 60 Hz and full range color
sampling. Being a truly versatile system, the Event Master offers a large range of scaled AUX outputs and
PGM outputs for full show control with a single box.
Native 4K input and output
With native 4K input and output, the Event master devices provide impressive pixel processing power.
Whether native or scaled inputs, two connectors or four, this HDCP-compliant system manages it all.
With up to 32 inputs and 14 outputs, the E2 system offers full show control, including 32 independent PIP
layers, 12 outputs and a dedicated two channel Multi-viewer. Thanks to its linkable chassis, it can easily
expand beyond the single chassis capacity, without the need for additional external processing and routing to
distribute the signals. And as its inputs and layers can also be extended, the E2 is even capable of managing
a blend of up to 32 4K projectors.
Simple servicing and control
The Event Master devices come with a straightforward cross-platform user interface that provides
touchscreen ergonomics. As the presets are stored on the chassis, it enables easy control via third-party
