Barco Event Master E2 Series User Manual

R5905948 /12 Event Master Devices18
Revision
Changes
11
• Changes initiated by software updates (version 6.2):
- Added Barcolink Ultra (4K) for SDI output on the Tri-Combo output card. Refer to
“Tri-Combo Output Card”, page 75.
- Increased the maximum number of Cues to 120. Refer to “Cue Menu > Cue
Workspace area”, page 242.
- Added instructions for creating, populating, and manipulating Super AUX
destinations. Refer to “Configuration Menu > Adjustment > Destination
Configuration”, page 145 and “Configuration Menu > Adjustment > Destination
Configuration > Adjust Panel”, page 157.
• Changes initiated by new hardware:
- Updated the altitude specifications and maximum ambient operating temperature
for EC-200/EC-210. Refer to “Installation requirements”, page 44.
- Added description of quad-channel DisplayPort 1.2 input card. Refer to “Quad
Channel DisplayPort 1.2 Input Card”, page 65.
- Added description of quad HDMI 2.0 output card. Refer to “Quad HDMI 2.0 Output
Card”, page 73.
- Updated the disassembly and assembly instructions for the Tri-Combo input and
Tri-Combo output cards. Refer to “Tri-Combo Input and Tri-Combo Output Card
Disassembly and Assembly”, page 391.
12
• Changes initiated by software updates (versions 6.3, 6.5, and 7.0):
- Added "Admin lock" mode in front panel of E2/S3 under the System menu. Refer to
“System menu > Admin Lock”, page 98.
- Added VPU Resource tab to the system diagram area of the configuration menu.
Refer to “Configuration Menu”, page 109.
- Added a list to show last 100 status bar messages on the bottom status bar. Refer
to “Configuration Menu”, page 109.
- Added EDID DisplayID block checkbox for DP 1.2 inputs. Refer to “Configuration
Menu > Adjustment > Input Configuration”, page 122, and see the “DVI, HDMI and
DisplayPort input types – bottom half” subsection.
- Added Gamma FX and Colorimetry for DisplayPort and HDMI. Refer to
“Configuration Menu > Adjustment > Input Configuration”, page 122, and see the
“Input adjustment panel > Main page” subsection, and refer to “Configuration Menu
> Adjustment > Output Configuration”, page 136, and see the “Output adjustment
panel > Connector menu” subsection.
- Added Flicker Filter controls for AUX Destination interlaced outputs. Refer to
“Configuration Menu > Add Screen Destinations & Layers”, page 285, and see the
“Output menu – Color submenu” subsection.
- Added a VESA calculator to the Custom Format Adjust tab. Refer to “Configuration
Menu > Adjustment > Custom Formats Configuration”, page 172, and see the
“Custom Format Adjust tab – bottom half” subsection.
- Added +Add Barco Projector and +Add Event Master XML buttons to the
External Devices tab. Refer to “Configuration Menu > Adjustment > External
Devices Configuration”, page 175, and see the “External Devices tab” subsection.
- Added "Freeze" mode as a User Key parameter. Refer to “Programming Menu >
Adjustment area > User Keys configuration”, page 232, and see the “User Keys
configuration menu description” subsection.
- Added "Auto Layout Dest" to Multiviewer. Refer to “Multiviewer Menu > Modifier
area”, page 249, and see the “Auto Layout Dest” subsection, and refer to
“Multiviewer Menu > Drop Inputs, Backgrounds and Destinations ”, page 299, and
see the “(Optional) Auto Layout Destination” subsection.
- Updated JSON APIs:
◦ Added "activateDestGroup".
◦ Added "TestPattern" parameter to "changeContent" and "changeAuxContent".
◦ Added "CueChanged" to "subscribe" and "unsubscribe" APIs.
Refer to “Event Master series processor JSON RPC remote control”, page 555.
