R5905948 /12 Event Master Devices 279
7.9 Backing up the system
WARNING: Backups from E2 work on E2 and E2 Gen2. Backups from E2 Gen2 are not backward
compatible with E2.
General
In this procedure, you will back up your system configuration to a USB drive.
Prerequisite
• Ensure that you are familiar with the USB device (Backup/Restore) Menu. For details on this menu,
please refer to chapter “System menu > USB device (Backup/Restore)”, page 90.
Back up a system configuration file
Use the following steps to back up your system to a USB Drive:
1. Insert a FAT32-formatted flash drive in the unit’s front-panel USB port.
2. From the System menu, scroll to the USB Backup/Restore submenu. Select Backup Config.
The USB Backup Config submenu appears. The navigation cursor appears at the default name for the first
backup file.
3. If you wish to change the default name of the backup configuration, press SEL. Use the ADJUST knob to
change the name, as described in section “Using menu system”, page 85. Press SEL again when you
complete the name change.
4. Scroll to Backup Config and press SEL.
A confirmation message appears when the backup is complete.
7.10 Configuration Menu > Initial Setup
General
In this procedure, you will run the Event Master Toolset Software (EMTS), verify communication between the
Event Master series processor (EMP) and the program to the local network and perform basic setup.
Prerequisite
• Ensure that you are familiar with the Configuration Menu. For details on this menu, please refer to
chapter “Configuration Menu”, page 109
Setup
1. Connect the PC running the EMTS to the same local network switch that the EMP is connected. Run the
EMTS, and the software should discover the EMP automatically. The unit is listed in the System configuration
page under the Discovered tab with the button on turning yellow.
2. Drag and drop the EMP from the device area into the middle diagram area.
3. If multiple units are connected to the PC, the yellow LEDs next to the system will turn green. You can assign a
unique name to each unit. Confirm that you are connected to the right unit by clicking the arrow in front of EMP
to reveal the unit’s IP address. Verify that this address is the same as the address listed on the unit’s front
panel on the top status menu.
Note: If the unit doesn’t connect automatically to the PC, you can type the PC’s IP address in the field
under “Manual Connect”. A reason for this can be the PC´s firewall settings. Be sure to allow full
communication for EMTS and EMP.
4. (Optional) Select the EMP´s native vertical refresh rate from the “System Native Rate:” drop-down menu.
Default value is 59.94Hz.
