R5905948 /12 Event Master Devices 547
A.20 Specifications of the Quad DP 1.2 input card
(Gen 2)
R9004793 – Quad DP 1.2 input card specifications
HDCP Supports HDCP version 1.3 on all input connectors.
Capacity Supports 4x 1200p@60 4:4:4, 4x 4K/UHD@30 4:4:4, or 2x 4K@60p/UHD
4:4:4 per card (single cable) in '8L' slot.
Input DP1.2 input supports up to UHD@60p, 4:4:4, 10 bit, (up to 660 Mpix/s).
A.21 Specifications of the Quad DP 1.2 output card
(Gen 2)
R9004765 – Quad DP 1.2 output card specifications
HDCP Supports HDCP version 1.3 on on connectors 1 and 2.
Capacity Supports 4x 1200p@60 4:4:4, 4x 4K/UHD@30 4:4:4, or 2x 4K@60p/UHD
4:4:4 per card (single cable).
Output DP 1.2 output supports up to UHD@60p, 4:4:4, 10 bit, (up to 660 Mpix/s)
A.22 Specifications of the 4K60 Tri-Combo input
card (Gen 2)
R9004785 – 4K60 Tri-Combo input card specifications
HDCP DP1.2 supports HDCP 1.3; HDMI 2.0 supports HDCP 1.4 and HDCP 2.2.
Capacity 1x 4K@60p, 2x high-speed (dual link type), or 4x HD outputs per card
SDI Input
• 12G-SDI supports up to UHD@60p, 4:2:2, 10 bit.
• Quad SDI 4K/UHD and 2SI (2 sample interleave) 4K/UHD formats
DisplayPort Input DP1.2 input supports up to UHD@60p, 4:4:4, 10 bit, (up to 660 Mpix/s).
HDMI Input HDMI 2.0 input supports up to UHD@60p, 4:4:4, 8 bit (up to 600 Mpix/s).
A.23 Specifications of the 4K60 Tri-Combo output
card (Gen 2)
R9004786 – 4K60 Tri-Combo output card specifications
HDCP DP1.2 supports HDCP 1.3; HDMI 2.0 supports HDCP 1.4 and HDCP 2.2.
Capacity 1x 4K@60p, 2x high-speed (dual link type), or 4x HD outputs per card
SDI Output
• 12G-SDI supports UHD@60p, 4:2:2, 10 bit.
• Quad SDI 4K/UHD and 2SI (2 sample interleave) 4K/UHD formats
DisplayPort Output DP 1.2 output supports up to UHD@60p, 4:4:4, 10 bit, (up to 660 Mpix/s).
HDMI Output HDMI 2.0 output supports up to UHD@60p, 4:4:4, 8 bit, (up to 600 Mpix/s).
