R5905948 /12 Event Master Devices 431

Image 14-79

7. Remove the cable from the unit.

How to install the Genlock Cable

To install the Genlock Cable follow the same procedure in the reverse order.

There is a key on the connector to prevent incorrect insertion of the cable.

Make sure the latches are fully engaged to prevent the cable from coming loose.

14.29 Ethernet Cable

Flow chart

Image 14-80

E2 Maintenance
