R5905948 /12 Event Master Devices 449
15.3 Spare Parts Serviceable by All Users
S3 Spare Parts list
P/N
Description
Comments
R767241K * VFD Display assembly
R767246K * VFD Filter
R767260K * Front Panel board
R767263K * Heatsink fan One for each Input, Output, Link and VPU card
R767264K * CPU module
R767265K * Motherboard Heatsink &
Fan kit
R767275K * Solid-State Memory
R767278K MOTHERBOARD S3
R767279K POWER INTERPOSER S3
R767280K * 3RU fan tray The fans are not available separately — will replace
R767271K
R767281K FRONT RACK EARS S3 Includes hardware for both sides
R767282K REAR CONNECTOR
PROTECTOR S3
R767283K S3 Cable Kit Kit contains:
• 1x USB Extension cable
• 1x Fan Tray-to-Motherboard cable
• 1x RJ45-to-Motherboard CAT5 Ethernet cable
• 1x Front Panel Keyboard-to-Motherboard flat cable
• 1x Genlock-to-Motherboard flat cable
• 1x VFD-to-Motherboard cable
R9004740 * DVI Input Board
R9004741 * SDI Output Board
R9004742 * SDI Input Board
R9004743 * HDMI Output Board
R9004744 * DP/HDMI Input Board
R9004745 * DVI Output Board
R9004746 * Link Card Board
R9004750 * Link/CXP Cable
R9004758 VPU CARD S3
R9004759 GENLOCK S3
R9004760 GENLOCK/S3D S3
R9004765* Quad DP 1.2 Output Board
R9004769 Power supply (PS) One PS only. System accepts two power supplies.
R9004785 * Tri-Combo Input Board
R9004786 * Tri-Combo Output Board
R9004791* Quad HDMI Input Board
R9004792* Quad HDMI 2.0 Output
Board
R9004793* Quad DP 1.2 Input Board
R9801120* Motherboard Battery Kit
(*) common between E2 and S3.
Optional CXP Cables
P/N Description Comments
R9004753 CXP Fiber Cable 1x 30M Fiber cable
R9004754 CXP Fiber Cable 1x 100M Fiber cable
R9004761 CXP Cable 1x 3M cable
S3 Maintenance
