Barco Event Master E2 Series - A.3 Specifications of E2 Gen 2

R5905948 /12 Event Master Devices536
• Flexible layer allocation – up to 8 mixable or 16 single scalable PIP/key
layers assignable to Program output screens
Scaled Aux outputs
• User definable for up to 4 x 2048x1200@60 or up to 1 x 4K@60
• All outputs can be defined as Aux destinations for a total of 8 Aux
outputs
• Output color correction
(Preview and Multiviewer not available in all configurations.)
Still stores Up to 100 HD depending on the import file size.
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma key
• PIP moves via Keyframes
Multiviewer
• Flexible user-definable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
• Dedicated hardware, same as E2 Event Master processors
Expandability Linking is available as an upgrade option.
HDCP HDCP compliance determined by installed cards.
Control
• Event Master screen management software for PC or MAC
• Ethernet RJ-45, 1000/100/10 Mbps autosense
• Field-Serviceable I/O and processing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies
Serviceability
• Field-serviceable I/O and processing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies
Noise level Max 52.9 dB avg. Fans at 100%. Fan speed is software-managed based
on operating temperature. Reference ISO 7779.
Dimensions
• Height: 17.8 cm (7.0 in) – 4 RU rackmount
• Width: 43.2 cm (17 in) without chassis handles, 48.3 cm (19 in) with
chassis handles attached
• Depth: 56.9 cm (22.4 in) from front panel to rear panel, 62.2 cm (24.5 in)
overall
Weight 27.8 kg / 61 lbs
Power
• Input power: 100–240 VAC 50/60Hz 700W
• Ships with dual-redundant, hot-swappable power supplies
Warranty 3 years parts and labor
Environmental temperature 0–40° C / 32–104° F
Environmental humidity 0–95% non-condensing
A.3 Specifications of E2 Gen 2
R9009203 – E2 Gen 2 Specifications
Model NGS-4U-V2
Live effects canvas
• Up to 20 Megapixels PVW/PGM
• 40 Megapixels PGM only
• 80 Megapixels @30p and PGM only
Specifications
