R5905948 /12 Event Master Devices 69
• Process up to four independent SDI signals with support for SD, HD, 3G, 6G and 12G in Single Link, Dual
Link (1.5G) or Quad Link (3G)
• Each input channel includes an LED that turns green when a valid sync is detected.
Specifications
DisplayPort
• DisplayPort per 1.2 specification
• Pixel clock up to 620 MHz
- Max pixel clock at 24 bits/pixel = 620 Mpix/sec
- Max pixel clock at 30 bits/pixel = 576 Mpix/sec
- Max pixel clock at 36 bits/pixel = 480 Mpix/sec
• Supported formats
- formats up to 4096x2160@60 (30 bits)
- 4K/UHD Supported:
â—¦ 3840x2,400/ 50/59.94/60 via 1x DP
â—¦ 4096x2,160/ 50/59.94/60 via 1x DP
â—¦ 3840x2,160/ 50/59.94/60 via 1x DP
• Supply up to 500 mA @ 3.3V on pin 20
- Allows the DP connector to power an external device
- Overcurrent protection provided by means of a re-settable fuse
• Multi-Stream Transport (MST)—not supported
• EDID version 1.3 compatible
• HDCP version 1.3 compatible
HDMI
• HDMI per 2.0 specification
• Pixel clock up to 600 MHz
- Max pixel clock at 24 bits/pixel = 600 Mpix/sec
- Max pixel clock at 30 bits/pixel = 480 Mpix/sec
- Max pixel clock at 36 bits/pixel = 400 Mpix/sec
• Supported formats
- formats up to 2560x1600@60 and 3840x1200@60 (30 bits)
- 4K/UHD Supported:
â—¦ 3840x2400/ 50/59.94/60 input via 1x HDMI
â—¦ 4096x2160/ 50/59.94/60 input via 1x HDMI
â—¦ 3840x2160/ 50/59.94/60 input via 1x HDMI
• EDID version 1.3 compatible
• HDCP version 1.4 and version 2.2 compatible
SDI
• Supported formats:
Signal
type
Min. BNC
connector
number
Max
channels
per card
Standard Examples
SD 1 4 SMPTE 259M-C 480i, 576i (NTSC/PAL)
HD 1 4 SMPTE 292M 1920x1080 @ 59.94i/50i
1920x1080psf @ 23.98/24/25/29.97/30
720x480 @ 60p/50p
3G 1 4 SMPTE 424M
Barcolink
1920x1080 @ 60p/50p
1920x1200 @ 60p/50p
6G 1 1 SMPTE 2081-10 3840x2160 @ 23.98/24/25/29.97/30
4096x2160 @ 23.98/24/25/29.97/30
12G 1 1 SMPTE 2082-10 3840x2160 @ 50/59.94/60
4096x2160 @ 50/59.94/60
