Barco Event Master E2 Series User Manual

R5905948 /12 Event Master Devices 77
• HDCP version 1.3 compatible
HDMI
• HDMI per 2.0 specification
• Pixel clock up to 600 MHz
- Max pixel clock at 24 bits/pixel = 600 Mpix/sec
- Max pixel clock at 30 bits/pixel = 480 Mpix/sec
- Max pixel clock at 36 bits/pixel = 400 Mpix/sec
• Supported formats
- formats up to 2560x1600@60 and 3840x1200@60 (30 bits)
- 4K/UHD Supported:
◦ 3840x2400/ 50/59.94/60 via 1x HDMI
◦ 4096x2160/ 50/59.94/60 via 1x HDMI
◦ 3840x2160/ 50/59.94/60 via 1x HDMI
• EDID version 1.3 compatible
• HDCP version 1.4 and version 2.2 compatible
SDI
• Supported formats:
Signal
type
Min. BNC
connector
number
Max
channels
per card
Standard Examples
SD 1 4 SMPTE 259M-C 480i, 576i (NTSC/PAL)
HD 1 4 SMPTE 292M 1920x1080 @ 59.94i/50i
1920x1080psf @ 23.98/24/25/29.97/30
720x480 @ 60p/50p
3G 1 4 SMPTE 424M
Barcolink
1920x1080 @ 60p/50p
1920x1200 @ 60p/50p
6G 1 1 SMPTE 2081-10 3840x2160 @ 23.98/24/25/29.97/30
4096x2160 @ 23.98/24/25/29.97/30
12G 1 1 SMPTE 2082-10
Barcolink Ultra (4K)
3840x2160 @ 50/59.94/60
4096x2160 @ 50/59.94/60
3840x2400 @ 50/59.94/60
4K / UHD 4 1 SMPTE 292M
SMPTE 2048-2
Image mapping: Quadrants
3840x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
4096x2160 @ 23.98/24/25/29.97/30 as 4x HD-
SDI
Hardware orientation
