R5905948 /12 Event Master Devices 323
P7: In this application we will not save any user keys. All layers attributes will be saved.
P7: Create user Keys and Presets
1. Select the Site screen destination and the layer in preview.
2. Under the Preset tab click in the “Save to new Preset” button.
3. Edit the name to reflect the source that is on Preview.
4. Repeat the previous steps to save 3 more presets, so we have a preset for both video clips and both cameras.
Image 9-24
5. Select the Main screen and select the sources into the two PIPs are the event requirements described in the
introduction of the application note.
6. Save each look into a preset and give it an appropriate name.
Result
Now you are ready to execute the presets and transition on the desire preview look into Program. Remember
to select the corresponding destinations when you use the All Trans button.
General operation example
