R5905948 /12 Event Master Devices 329
EC-200/EC-210 large
controller
EC-50 small controller
EC-30 compact controller
7 Function buttons and numpad NA NA
8 Wheel (rotary encoders)
layout
NA NA
EC-200/EC-210 General description
The Event Master EC-200/EC-210 controller is dedicated computing hardware. Its front has a keyboard area
and two touchscreens, and the back has connectors. It runs its software, the Event Master Toolset, on an
industrial Linux operating system.
Tactile operation with buttons and touchscreen displays allow for easy and direct control of the Event Master
series processors.
EC-50 General description
The small form factor of the EC-50 is equally at home next to an EC-200/EC-210 or as part of a Event Master
Toolset Win PC or MAC OSX System.
It provides a traditional T-Bar and button interface for the Destination, layer and preset functions of the
EventMaster Toolset.
It uses the same high quality controls as found in the EC-200/EC-210 console, ensuring responsive and
reliable operation.
A 15.6 inch HD widescreen with 10 point multi touch is integrated in the controller allowing you to connect a
screen output from your host system.
One LED desk light is supplied, fully dimmable and software controllable. The other light intensities are also
adjustable via the EMTS Settings Menu page.
EC-30 General description
The compact EC-30 is a USB peripheral added to an Event Master control computer. It provides essential
selections for sources, presets, layers, and destinations.
Controller Orientation
