About this chapter
This chapter describes how to service a S3 series Event Master Processor by replacing individual
components.
Simple servicing
S3 series devices are based on a modular design that ensures easy serviceability. Users can swap most of
the S3 components in the case of damage, without shipping the unit to a Barco service center.
Methodology
Most procedures in these chapters include multiple steps to gain access to the parts requiring service. A
workflow flow chart is provided next indicating all of the procedures and their relationships. Please refer to the
chart to familiarize yourself with the sequence of procedures.
ESD recommendations
The following precautions must be taken:
• Perform the Service procedures only at approved anti-static work station equipped with anti-static mat.
• At all times use a conductive wrist strap attached to a solid earth ground.
• Always discharge yourself by touching a grounded bare metal surface before coming in contact with ESD
sensitive electronic.
WARNING: Always switch power off and unplug the cords from the device before performing any
maintenance operations described in this chapter.
WARNING: The device can be damaged by electrostatic discharge (ESD). When handling the
device and any of its components, caution must be taken so that damage does not occur. Damage
due to inappropriate handling is not covered by the warranty.
