MAGNETIC BASE MOUNTING
PRODUCT REFERENCE GUIDE
5
OPTIONAL STAND/RISER/MOUNT
An optional Tilting Stand, Riser and Wall Mount are available for use with the scanner. Both
the Stand and Riser have anti‐skid pads on the bottom and can rest on any desired horizon‐
tal surface or countertop. The scanner (along with the stand/riser) can be easily reposi‐
tioned on the counter or lifted for portable use. The Wall Mount can be secured to a
v
ertical surface.
For more information go to
Installing the Tilting Stand / Riser, starting on page 6, or Dimen-
sions on page 12.
Figure 4. Tilting Stand, Riser and Wall Mounts
Tilting Stand
Riser
Wall Mounts
Rear Mount
Side Mount
,
Magnetic Base Mounting
The magnetic swivel base can be used to semi‐permanently attach a scanner to a flat sur‐
face using the provided screw. Both the stand and riser options mount onto the magnetic
swi
vel base and are held magnetically in place. The scanner can easily be rotated to a
desired orientation. The scanner (along with the riser or stand) can be detached for porta‐
ble use by lifting the entire unit.
To Next Page
