ENTER/EXIT PROGRAMMING MODE
156 MAGELLAN™ 1500I
EAN-8 Decoding Levels
Decoding levels allow the decoder to be set to perform at one of four selectable levels:
• Very Conservative — Slower scan time, virtually eliminates misreads. The most secure
setting.
• Slightly More Aggressive — Faster scanning, more aggressive, yet minimizes misreads.
• Moderately Aggressive — Even faster scanning, even more aggressive.
• Very Aggressive — Fastest scan speed, most aggressive.
CAUTION
Use caution when setting this feature, as more aggressive settings for
this feature allow a higher potential for misreads.
EAN-8 Decoding Level = Very Conservative
EAN-8 Decoding Level = Slightly More Aggressive
EAN-8 Decoding Level = Moderately Aggressive
EAN-8 Decoding Level = Very Aggressive
DEFAULT
050E01(CR)
050E02(CR)
050E03(CR)
050E04(CR)

Datalogic Magellan 1500i Specifications

General

Type	Fixed bar code reader
Sensor type	LED
Scanner type	2D
Yaw reading angle	-75 - 75 °
Scanner resolution	0.13 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 86.1 lx
Linear (1D) barcodes supported	-
Optical sensor resolution (W x H)	1280 x 800 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Input voltage	5 V
Power consumption	500 mA
Power source type	USB
Buzzer	Yes
Certification	EN62471, IEC62471
Product color	Black
Housing material	Plastic
Image formats supported	BMP, JPEG
International Protection (IP) code	IP52
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
USB version	2.0
Connectivity technology	Wired
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	75 mm
Width	60 mm
Height	150 mm
Weight	240 g
