section
D 5
651098/1098S - M.Y. 2007 - edition 00
Use and maintenance
The values can be reset by pressing the “Reset” icon.
If the cylinders are not balanced, turn the bypass screw (20) of the cylinder with the lowest vacuum level (the highest value)
backing it off slightly (a 1/4 turn at a time) until the two lines on the graph coincide, or until identical numerical values are displayed,
if numerical display is selected.
20
20
