L 8
351098/1098S - M.Y. 2007 - edition 00
Fuel / Exhaust System
Unscrew the bolt (7) and the nut (18) securing the pipe (21) to the frame.
Remove the springs (3) and withdraw the vertical cylinder head exhaust pipe (21) from the horizontal cylinder head exhaust
pipe (4) and the exhaust manifold (9).
7
21
7
18
21
4
3
21
9
3
21
