38 1098/1098S - M.Y. 2007 - edition 00
Fuel / Exhaust System
Secure the vertical head exhaust pipe (21) to the frame with the bolt (7) and nut (18) and tighten the bolt (7) to the specified torque
(Sect. C 3, Frame torque settings).
Connect the lambda sensor (11) to the wiring (D).
7
18
21
7
21
D
11
