Fuel / Exhaust System
To adjust the cables, turn the adjusters (F).
Refit the heat shield (22) and tighten the bolts (24) to the specified torque (Sect. C 3, Frame torque settings).
Connect the silencers (29) and (30) to the pipe (21) and locate the springs (3).
Refit the bolt (17) with the nut (8) and tighten to the specified torque (Sect. C 3, Frame torque settings).
