Engine
Working from the inside of the cover, remove the seat (8) of the mechanical seal (9).
Remove the inner spacer (7).
Check the condition of the components of the mechanical seal: there should be no signs of deformation, cracking, or excessive
wear. In the case of damage, both components must be renewed.
