N 6.1
1211098/1098S - M.Y. 2007 - edition 00
Engine
Overhaul of the pressure plate
Check the condition of the bearing: renew the bearing if the play is excessive.
Check the contact surface of last plain steel plate. If extremely scored, polish it in the same manner as described previously for
the cylinder head surface.
Check the condition of the spring guide cups and always replace the spring retaining collars.
Overhaul of the clutch springs
Measure the length “L” of each spring:
Minimum length: 36.5 mm.
Renew any springs that are shorter than the above limit value.
L
