N 9.2
202 1098/1098S - M.Y. 2007 - edition 00
Engine
Check that the oilways are free of restrictions or clogging.
Check the condition of locating dowels (22). In the event of signs of distortion or excessive assembly clearance with the
corresponding seats, remove the locating dowels using appropriate tools.
If it proves difficult to remove the dowels (22) from the crankcase, use a tap with a left-hand thread to force them out.
Important
The dowels (22) must always be renewed when they have been removed using the above procedure.
Remove the bearing (23), the circlip (5) and the roller bearing (4).
22
22
23
4
5
