6 1098/1098S - M.Y. 2007 - edition 00
Electric system
Wiring colour codes
B Blue
Bk Black
Bn Brown
G Green
Gr Grey
Lb Light blue
O Orange
P Pink
R Red
V Violet
W White
Y Yellow
Key to fusebox
Pos. Item Val.
1 Key-on 10 A
2 Lights 15 A
3 Device 15 A
4 Instrument panel 5 A
5 Injection 20 A
6 Engine Electronic Control Unit 5 A
7 Fans 7.5 A
1 2 3 4 5 6 7
