103
6-1-8. EMB2 AUDIO CLOCK
E M B 2 A U D I O C L O C K
108
G R O U P 1 : R E F E R E N C E
G R O U P 2 : R E F E R E N C E
G R O U P 3 : R E F E R E N C E
G R O U P 4 : R E F E R E N C E
Parameter
Default
Setting range
Description
GROUP 1
REFERENCE
AUTO
REFERENCE
INPUT CH 1/2
INPUT CH 3/4
Selects an audio clock signal per group
for SDI embedded audio output from
FS2.
AUTO: Automatically selects audio clock
input in the NON-PCM signal channel, if
an input NON-PCM signal is in the
selected SDI embedded audio group.
Automatically selects audio clock signal
in the smallest numbered channel, if all
signals in the audio group are NON-PCM.
Automatically selects audio clock signal
synchronized to the output video signal, if
all signals in the audio group are PCM.
*2
REFEFENCE: Audio clock signal
synchronized to the output video signal.
(Used to synchronize audio with the video
signals processed in the SRC.)
CH 1/2 to 15/16: Audio clock input in
SOURCE channels CH 1/2 to 15/16.
*1
To output asynchronous audio signals,
select one input channel pair for each
group.
*2
For SD-SDI outputs, REFERENCE is
automatically selected regardless of the
settings.
GROUP 2
REFERENCE
AUTO
REFERENCE
INPUT CH 5/6
INPUT CH 7/8
GROUP 3
REFERENCE
AUTO
REFERENCE
INPUT CH 9/10
INPUT CH 11/12
GROUP 4
REFERENCE
AUTO
REFERENCE
INPUT CH 13/14
INPUT CH 15/16
*1 See section 6-5 AUDIO MAPPING (MAPPING) for details on SOURCE settings.
*2 Embedded audio signals are divided into 4 groups. Each group consists of 4 audio
channels; Group 1 (CH 1 to 4), Group 2 (CH 5 to 8), Group 3 (CH 9 to 12), Group 4 (CH 13
to 16). The audio signals in the same group are transmitted together using the same audio
clock (48kHz). PCM audio signals will be synchronized to a genlock signal in the SRC
(sampling rate converter) so as to synchronize with the output video signal. Non-PCM
audio signals (compressed audio data such as AC-3) do not go into SRC. If the NON-PCM
audio input signal is asynchronous with the output video signal, the NON-PCM audio
output signal will be asynchronous. The asynchronous NON-PCM audio signals can be
embedded to SDI video signals by selecting an audio clock for each audio group. To do so,
all 4 channels in the respective audio groups must be synchronous. Assign 4 synchronous
audio signals to channels in a group. (See section 6-5-2. EMB2 OUT REMAP for details.)
Then the asynchronous audio signal will be properly embedded to the video signal.
Menu button
PROCESS
SDI AUDIO
