FOR-A FA-9520 - Dolby OPB AUX

93
5-10-19. Dolby OPB AUX
* This menu is displayed only if FA-95D-D option is installed in option slot B.
Dolb y O P B A U X
596
I N P U T B : L O S S
O U T P U T B : N O N E
R E F E R E N C E B : L O S S
Parameter
Display
Description
INPUT B
LOSS
PCM
NON-PCM
UNKNOWN
Displays status or type of signal input to the
optional Dolby input connector (Dolby IN) in
slot B.
LOSS: No audio signal
PCM: Standard audio signal
NON-PCM: Compressed audio data such as
Dolby E encoded data
UNKNOWN: Unknown signal.
OUTPUT B
PCM
NON-PCM
NONE
Displays status or type of signal output to the
optional Dolby output connectors (Dolby OUT)
in slot B.
PCM: Standard audio signal
NON-PCM: Compressed audio data such as
Dolby E encoded data
NONE: No signal
REFERENCE B
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
UNKNOWN
Displays signal format of reference signal input
to the optional Dolby REF IN connector in slot
B.
LOSS: No signal
UNKNOWN: Unknown signal format
Menu button
STATUS
OTHER
