FOR-A FA-9520 - Out; Wss out

96
5-10-25. VI OUT
Displays whether the RP186 VI ancillary data is inserted into FS1/FS2 output video signals.
 When no RP186 VI is in the output video signal
VI OUT
6 47
R P 1 8 6 V I : A B S E N T
If ANC MODE in 5-9-6 ANC SET is set to H/V ANC, the state of the V ANC setting (PASS or
BLANK) is displayed.
 When RP186 VI is in the output video signal
VI OUT
6 47
R P 1 8 6 V I : P R E S E N T
A F D : 0 2 S S : 0 2
B O X 1 6 : 9 T O P
D 1 : 1 2 D 2 : 0 2 D 3 : 0 2
Displays the status of RP186 VI (Video Index) Class1.
AFD: Active Format Description is displayed in hexadecimal format.
SS: Scanning System is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
D1-D3: Detected Data are displayed in hexadecimal format.

See section 20-6 “AFD Code Abbreviations” for details on AFD types.
5-10-26. WSS OUT
 When no BT1119-2 WSS is in the FS1/FS2 output video signals
WSS OUT
6 48
B T 1 1 1 9 W S S : A B S E N T
If ANC MODE in 5-9-6 ANC SET is set to H/V ANC, the state of the V ANC setting (PASS or
BLANK) is displayed.
 When BT1119-2 WSS is in the FS1/FS2 output video signals
WSS OUT
6 48
B T 1 1 1 9 W S S ： P R E S E N T
AFD:04
B O X 1 6 : 9 T O P
BIT13- 0 : 0 0 0 4
Displays the status of BT1119-2 WSS.
AFD: Active Format Description is displayed in hexadecimal format.
SS: Scanning System is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
D1-D3: Detected Data are displayed in hexadecimal format.

See section 20-6“AFD Code Abbreviations” for details on AFD types.
Menu button
STATUS
OTHER
FS1/LOCK
FS2/LOCK
Menu button
STATUS
OTHER
FS1/LOCK
FS2/LOCK
Menu button
STATUS
OTHER
FS1/LOCK
FS2/LOCK
Menu button
STATUS
OTHER
FS1/LOCK
FS2/LOCK
