5-9-14. COMPOSITE SET1
C O M P O S I T E S E T 1
C O M B F I L T E R : 3 D
C R O S S C O L O R : O F F
Adjusts the subcarrier phase of composite
and Y/C output signals referring to the B.B.
genlock signal.
Not adjustable with the tri-level genlock
signal. In such case, the menu will appear
as “NOT ADJUST”.
Selects a mode to separate the Y
(luminance) and C (chrominance) of
composite signals.
Sets the noise reduction level for the
composite signal inputs.
Sets the cross color (noise) reduction
level.
*1 The setting is effective on Y/C and composite outputs on the FA-95AIO option installed in
option slot A and/or B.
5-9-15. COMPOSITE SET2
C O M P O S I T E S E T 2
N T S C S E T U P : O F F
PAL- M M O D E : D I S A B L E
ON: Passes through VITS (V-ANC) lines 10 to
21 (NTSC), or 6 to 23 (PAL) of composite input
signals. For SD-SDI output signals, inserts
VITS lines into Y signals.
Set to OFF for signals without 7.5 IRE setup.
Set to ON for signals with 7.5 IRE setup.
DISABLE: Allows NTSC signals to be output.
ENABLE: Allows PAL-M signals to be output.
*2
*1 The setting is effective on Y/C and composite I/O on the FA-95AIO option installed in
option slot A and/or B.
*2 This setting enables PAL-M output for COMPOSITE OUT and Y/C
*1
outputs, however,
NTSC signal output will be disabled.
To synchronize the PAL-M output, input a PAL-M BB or 59.94/29.97 Hz tri-level sync
signal to the GENLOCK IN connector. (NTSC BB signals cannot synchronize PAL-M
output signals.)
PAL signals can always be input and output regardless of this setting.
