4-2-3. Arrow Buttons
Double-arrow buttons (up and down)
<NORMAL mode>
The double-arrow buttons allow you to go to the first menu of the video or audio menus that
are assigned to the respective menu buttons or first menus of major setting menus
(designated by “” in the above menu list).
<LIVE SAFE mode>
Button functions are the same as NORMAL mode, however, double-arrow buttons are
inoperative while single-arrow buttons are blinking (indicating the FA-9520 is in the setting
change confirming state, because a parameter in one of the menus requiring a setting change
confirmation has been changed).
Single-arrow buttons (up and down)
< NORMAL mode>
The single-arrow buttons allow you to move between menus within the menus that are
assigned to respective menu buttons.
When it reaches the last menu, the light goes off.
< LIVE SAFE mode>
Single-arrow buttons blink when a parameter in one of the menus requiring a setting change
confirmation is changed. To confirm the change, press the single down arrow button. Pressing
the single up arrow button cancels the change, and the parameter before change will be
displayed.
While single-arrow buttons are blinking, all buttons except single-arrow buttons are disabled
until either single-arrow button is pressed.
Menus that request a setting confirmation are shown with a black circle (●) in the menu list in
section 4-2-2. “Menu Buttons”.
NORMAL and LIVE SAFE modes can be switched in the FRONT OPERATION menu
(see section 7-4).
4-2-4. Consecutive Viewing of Settings
<NORMAL mode>
While a menu button is turned on, the menu display will be in consecutive display mode when
both single (up and down) arrow buttons are pressed simultaneously. Both single arrow
buttons blink when they are in consecutive display mode. To exit the mode, simultaneously
press both arrow buttons again. Then arrow buttons will stop blinking.
The single down and up arrow buttons, while in consecutive display mode, can consecutively
display all menus in which menu list settings can be changed, from the first to last or last to
first menu item. Meanwhile, holding down the single down or up arrow button also allows you
to consecutively view menus.
<LIVE SAFE mode>
Button functions are the same as NORMAL mode, however, consecutive display mode is
inoperative while single-arrow buttons are blinking (indicating the FA-9520 is in the setting
change confirming state, because a parameter in one of the menus requiring a setting change
confirmation has been changed). Consecutive display mode will be canceled when a setting
is changed.
Order of Consecutive Menu Display
VIDEO Menus (Lit green)
The single down-arrow button consecutively displays menu pages from VIDEO PROC AMP
of PROCESS to ANC OUT1 of STATUS in the menu list in section 4-2-2. On the other hand,
the single up-arrow button consecutively displays menu pages from ANC OUT1 of STATUS to
VIDEO PROC AMP of PROCESS in the menu list.
