FOR-A FA-9520 - Dolby DECODER REFERENCE; Dolby DOWNMIX

127
6-10-1-3. Dolby DECODER REFERENCE
This menu is displayed only if the FA-95D-D or FA-95DE-E option is installed in slot A.
D o l b y D E C R E F A
183
INPUT :NONE
Menu names and menu pages for the option in slot B change as shown below.
D o l b y D E C R E F B
233
Parameter
Default
Setting range
Description
INPUT
NONE
NONE
FS1 OUTPUT
FS2 OUTPUT
AUX REF IN
FS1 INPUT
FS2 INPUT
Selects a reference signal to be used in the
Dolby decoder. PCM signal output from the
Dolby decoder will be synchronized to the
selected reference signal.
NONE: No reference signal used
FS1/2 OUTPUT: Uses the respective FS
output video signals.
AUX REF IN: Uses the input signal in the
optional Dolby reference input connector
(REF IN). If no signal is in the REF IN
connector, the PCM signal output will be in
free-run mode.
FS1/2 INPUT: Uses the respective FS
input video signals.
6-10-1-4. Dolby DOWNMIX
This menu is displayed only if the FA-95D-D or FA-95DE-E option is installed in slot A.
D o l b y D O W N M I X A
184
M O D E : S U R R O U N D
Menu names and menu pages for the option in slot B change as shown below.
D o l b y D O W N M I X B
234
Parameter
Default
Setting range
Description
MODE
SURROUND
SURROUND
STEREO
MONAURAL
Selects a downmix mode for the Dolby
decoder.
Menu button
VIDEO OP
AUDIO OP
Menu button
VIDEO OP
AUDIO OP
