FOR-A FA-9520 User Manual

114
6-5-4. ANALOG OUT REMAP
ANALOG OUT R E M A P
144
CH SEL:CH1
ASSIGN:A N A L O G C H 1
Parameter
Default
Setting range
Description
CH SEL
CH1
CH1 - 8
Selects an audio output
channel to output analog audio
signal from CH1 through 8.
ASSIGN
ANALOG CH1 - 4
EMB1 CH1-16
EMB2 CH1-16
AES CH1-8
*1
ANALOG CH1-4
DOWN MIX1-L
DOWN MIX1-R
DOWN MIX2-L
DOWN MIX2-R
500Hz TONE
1KHz TONE
SILENCE
Dolby DECA CH1-8
*2
Dolby DMA-L
*2
Dolby DMA- R
*2
Dolby DECB CH1-8
*3
Dolby DMB-L
*3
Dolby DMB- R
*3
Selects a signal to be output
from the analog audio output
channel that is selected under
CH SEL.
LOUD1A
*4
LOUD2A
*4
LOUD1B
*5
LOUD2B
*5
L
R
C
LFE
Ls
Rs
FROM
SDI IN1
SDI IN2
-----
Displays the source signal input
channel of the embedded audio
signal for EMB1 CH1-CH16, or
EMB2 CH1-CH16 selected
under ASSIGN.
*1 If the AES connector is set to be used for input, the selected AES channel will be displayed
with an “＊“ as “＊AES CH1“ and no audio signal will be output. To change AES I/O
settings, see section 6-2-4. “AES I/O SETUP“ for details.
*2 Not shown if the FA-95D-D or FA-95DE-E option is not installed in option slot A.
*3 Not shown if the FA-95D-D or FA-95DE-E option is not installed in option slot B.
*4 Not shown if the FA-95ALA option is not installed in option slot A.
*5 Not shown if the FA-95ALA option is not installed in option slot B.
Menu button
CONV1
ANALOG
