11. ANALOG/DIGITAL Audio Input/Output Level
11-1. Analog Output Level Relative to the Digital Input Level
 Digital Reference Level: -18dBFS
ANALOG OUT LEVEL setting
Digital audio input level
-10 dBm
0 dBm
4 dBm
8 dBm
-24 dBFS
-16 dBm
-6 dBm
-2 dBm
+2 dBm
-20 dBFS
-12 dBm
-2 dBm
+2 dBm
+6 dBm
-18 dBFS
-10 dBm
0 dBm
+4 dBm
+8 dBm
0 dBFS
+8 dBm
+18 dBm
+22 dBm
CLIP
 Digital Reference Level: -20dBFS
ANALOG OUT LEVEL setting
Digital audio input level
-10 dBm
0 dBm
4 dBm
8 dBm
-24 dBFS
-14 dBm
-4 dBm
0 dBm
+4 dBm
-20 dBFS
-10 dBm
0 dBm
+4 dBm
+8 dBm
-18 dBFS
-8 dBm
+2 dBm
+6 dBm
+10 dBm
0 dBFS
+10 dBm
+20 dBm
+24 dBm
CLIP
 Digital Reference Level: -24dBFS
ANALOG OUT LEVEL setting
Digital audio input level
-10 dBm
0 dBm
4 dBm
8 dBm
-24 dBFS
-10 dBm
+0 dBm
+4 dBm
+8 dBm
-20 dBFS
-6 dBm
+4 dBm
+8 dBm
+12 dBm
-18 dBFS
-4 dBm
+6 dBm
+10 dBm
+14 dBm
0 dBFS
+14 dBm
+24 dBm
CLIP
CLIP

See REF LEVEL in section 6-11-2. "DIGITAL AUDIO" for details on the Digital
Reference Level setting.
See section 6-3-3. "ANALOG OUT LEVEL" for details on the ANALOG OUT
LEVEL setting.
