217
9-6-2. Backup Parameter
The FA-9520 settings can be saved to a file, and the saved settings in a file can be loaded.
Saving the FA-9520 Settings to a File
Click Submit next to Save File under Backup Parameter. The File Download dialog appears.
Click OK to start saving.
Some versions of Internet Explorer may not save data having a long file name
properly. In such case, save data in Internet Explorer using a short file name, then
rename the file in Windows Explorer. A data file can also be saved under its default file
name in any version of Internet Explorer.
Loading the Data Saved in a File
In Apply Setting Below, select the checkboxes of the items you wish to load the data. If no
checkbox is selected, no settings are loaded. See section 9-8-2. “NETWORK SETTING” for
details on the checkboxes in Network Setting. See section 9-8-3. “SNMP SETTING“ for
details on the checkboxes in SNMP Setting. Selecting the Parameter checkbox loads all
parameters except for Event Memory. Selecting the Event Name checkbox loads the event
memory names. See Set Event Name in section 9-6-1 “Event Control” for details. After
selecting the items to be loaded and clicking Browse, the Choose file dialog appears.
Specify the destination directory and click Open.
