6-5. AUDIO MAPPING (MAPPING)
Allows you to assign embedded audio, AES audio, and analog audio signals to output channels.
6-5-1. EMB1 OUT REMAP
Selects an FS1 audio channel to
embed audio signal from CH1
through 16.
EMB1 CH1-16
EMB2 CH1-16
AES CH1-8
*1
ANALOG CH1-4
DOWN MIX1-L
DOWN MIX1-R
DOWN MIX2-L
DOWN MIX2-R
500Hz TONE
1KHz TONE
SILENCE
Dolby DECA CH1-8
*2
Dolby DMA-L
*2
Dolby DMA- R
*2
Dolby ENCA CH1-2
*3
Dolby DECB CH1-8
*4
Dolby DMB-L
*4
Dolby DMB- R
*4
Dolby ENCB CH1-2
*5
Selects an audio signal to embed
into the FS1 audio channel
selected under CH SEL.
LOUD1A
*6
LOUD2A
*6
LOUD1B
*7
LOUD2B
*7
Displays the input signal from which
the selected embedded audio signal
is input, if ASSIGN is set to one
among EMB1 CH1 through 16 and
EMB2 CH1 through 16.
*1 If the AES connector is set to be used for input, the selected AES channel will be displayed
with an “＊“ as “＊AES CH1“ and no audio signal will be output. To change AES I/O
settings, see section 6-2-4. “AES I/O SETUP“ for details.
*2 Not shown if the FA-95D-D or FA-95DE-E option is not installed in option slot A.
*3 Not shown if the FA-95DE-E option is not installed in option slot A.
*4 Not shown if the FA-95D-D or FA-95DE-E option is not installed in option slot B.
*5 Not shown if the FA-95DE-E option is not installed in option slot B.
*6 Not shown if the FA-95ALA option is not installed in option slot A.
*7 Not shown if the FA-95ALA option is not installed in option slot B.
Auto Channel Pairing for NON-PCM Audio Inputs
The FA-9520 recognizes NON-PCM audio input signals in L/R channel pair units, and adjusts
assignments according to the signal selected for the L channel.
Ex. L/R channel pairs in EMB1: CH1/CH2, CH3/CH4......CH15/CH16.
The channel assignments that are changed by the adjustment will be shown with “＊” as
“CH1:＊EMB1 CH1”.
