4-2-2. Menu Buttons
The VIDEO/AUDIO button at the bottom right switches between the video and audio-related
menus. Pressing the button alternates the button to work as video menu buttons (lit green)
and audio menu buttons (lit orange). The menus at the top of each button label are video
menus (lit green), and the menus at the bottom are audio menus (lit orange). Menus that
request a setting confirmation in LIVE SAFE mode are shown with a black circle (●) in the
following list.
EMB1 IN GAIN
EMB1 OUT MONO
● EMB1 IN SET
● EMB1 OUT CLOCK
EMB2 IN GAIN
EMB2 OUT MONO
● EMB2 IN SET
● EMB2 OUT CLOCK
⊚WHITE LEVEL
⊚BLACK LEVEL
⊚GAMMA LEVEL
COLOR CORRECT
AES IN GAIN
AES HYSTERESIS
AES OUT MONO
● AES I/O SETUP
*3
● CONV MODE
CONV SIZE/POS
CONV CROPPING
CONV IMPROVE
CONV SIDE RGB
ANALOG IN LEVEL
ANALOG IN GAIN
ANALOG OUT LEVEL
ANALOG OUT MONO
● ANALOG IN SYSTEM
MASTER OUT GAIN
EMB1 OUT GAIN
EMB2 OUT GAIN
AES OUT GAIN
ANALOG OUT GAIN
●AVO SETTING
USER1-5 LEVEL SET
USER1-2 AREA SET
AVO SETUP
*1
● EMB1 OUT REMAP
● EMB2 OUT REMAP
● AES OUT REMAP
● ANALOG OUT REMAP
YPbPr/RGB CLIP
COMPOSITE CLIP
EMB1 IN DELAY
EMB2 IN DELAY
AES IN DELAY
ANALOG IN DELAY
● FS INPUT SELECT
ANC DETECT LINE
ANC DETECT SEL
● AIO A IN MODE
*1
● AIO B IN MODE
*2
● DOWN MIX1 SET
● DOWN MIX1 ASSIGN
● DOWN MIX2 SET
● DOWN MIX2 ASSIGN
● OUTPUT ASSIGN
● AIO A ASSIGN
*1
● AIO B ASSIGN
*2
ANC DATA EMBED
ANC EMBED LINE
● EMB1 SRC MODE
● EMB2 SRC MODE
● AES SRC MODE
● EMB1 POLARITY
● EMB2 POLARITY
● AES POLARITY
● ANALOG POLARITY
● Dolby AUX OUT A
*6*8
● Dolby DEC IN A
*6*8
● Dolby DEC REF A
*6*8
● Dolby DOWNMIX A
*6*8
Dolby DEC GAIN A
*6*8
● Dolby ENC INPUT A
*8
● Dolby ENC SET A
*8
● METADATA INPUT
*8
◇LOUD MEASURE 1A
*4
LOUD CTRL ENA1A
*4
LOUD CTRL SET1A
*4
LOUD CH ASGN1A
*4
◇LOUD MEASURE 2A
*4
LOUD CTRL ENA2A
*4
LOUD CTRL SET2A
*4
LOUD CH ASGN2A
*4
◇
● Dolby AUX OUT B
*7*9
● Dolby DEC IN B
*7*9
● Dolby DEC REF B
*7*9
● Dolby DOWNMIX B
*7*9
To Next Page
