FOR-A FA-9520 User Manual

101
6-1-5. EMB2 IN GAIN
E M B 2 I N G A I N
105
C H S E L : C H 1
G A I N S E T : 0 . 0 d B
M A S T E R : 0 . 0 d B
Parameter
Default
Setting range
(Steps)
Description
CH SEL
CH1
CH1 - CH16
Selects an FS2 embedded audio
channel for which to adjust the gain.
GAIN SET
0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
*1
Sets the input gain for the SDI embedded
audio channel that is selected under CH
SEL.
MASTER
0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
Sets the offset to the input gain for all
channels CH1 to CH16 of SDI-embedded
audio.
*1 The total value of GAIN SET and MASTER should not exceed the setting range. If the
range is exceeded, the alert will be displayed as *20.0 dB or *-20.0 dB.
6-1-6. EMB2 OUT MONO
E M B 2 O U T M O N O
106
C H S E L : C H 1 / 2
M O N O S U M ： D I S A B L E
Parameter
Default
Setting range
Description
CH SEL
CH1/2
CH1/2-15/16
Selects a stereo pair of FS2 embedded
audio channels.
MONO SUM
DISABLE
DISABLE
ENABLE
ENABLE: Outputs the stereo pair channels
selected under CH SEL as a mono sum.
(The signals of the selected pair channels
are added and divided by two to output from
each channel.)
Menu button
PROCESS
SDI AUDIO
Menu button
PROCESS
SDI AUDIO
