FOR-A FA-9520 - Video Position

72
5-9-4. VIDEO POSITION
V I D E O P O S I T I O N
64
H P O S : 0 P I X E L
V P O S : 0 L I N E
Parameter
Default
Setting range
(Steps)
Description
H POS
0
525/60 ±92
625/50 ±92
1080/59i ±240
1080/50i ±240
1080/23PsF ±240
1080/24PsF ±240
720/59p ±160
720/50p ±160
1080/59p ±240
1080/50p ±240
(PIXEL)
Adjusts the horizontal/vertical
position of output videos.
V POS
0
525/60 ±30
625/50 ±36
1080/59i ±68
1080/50i ±68
1080/23PsF ±68
1080/24PsF ±68
720/59p ±90
720/50p ±90
1080/59p ±135
1080/50p ±135
( LINE)
* Settings can be set for FS1 and FS2, respectively.
FS1/LOCK
FS2/LOCK
Menu button
VIDEO SYS
AUDIO SYS
