5-10-15. SDI 3/4 OUT AUDIO
S D I 3 / 4 O U T A U D I O
5 7 5
CH 1:P C M
CH 2:P C M
CH 3:P C M
CH 4:P C M
S D I 3 / 4 O U T A U D I O
5 7 6
CH 5:P C M
CH 6:P C M
CH 7:P C M
CH 8:P C M
S D I 3 / 4 O U T A U D I O
5 7 7
CH 9:P C M
CH10:P C M
CH11:P C M
CH12:P C M
S D I 3 / 4 O U T A U D I O
5 7 8
CH13:P C M
CH14:P C M
CH15:P C M
CH16:P C M
Parameter
Display
Description
CH1 - CH16
PCM
SILENCE
NON-PCM
UNKNOWN
BLANK
BY-PASS
Displays the status of audio signal channels CH1
through CH16 of the SDI 3/4 output.
PCM: Normal audio signal
SILENCE: Mute signal
NON-PCM: Compressed audio data such as AC3
UNKNOWN: Unidentifiable
BLANK: No audio signal embedding
BY-PASS: By-passed through
5-10-16. AES OUT AUDIO
A E S O U T A U D I O
5 87
C H 1 : P C M
C H 2 : P C M
C H 3 : P C M
C H 4 : P C M
A E S O U T A U D I O
5 88
C H 5 : P C M
C H 6 : P C M
C H 7 : P C M
C H 8 : P C M
Parameter
Display
Description
CH1 - CH8
PCM
SILENCE
NON-PCM
UNKNOWN
INPUT SETTING
Displays the status of the audio signal output from the
DIGITAL AUDIO IO connectors.
PCM: Normal audio signal
SILENCE: Mute signal
NON-PCM: Compressed audio data such as AC3
UNKNOWN: Unidentifiable
INPUT SETTING: Connector is set to input
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
