138
6-11-2. DIGITAL AUDIO
R E F L E V E L : - 2 0 d B F S
G R A D E : P R O F E S S I O N A L
R E S O L U T I O N : 2 4 b i t
Selects the reference level for
digital audio signals.
See section 11-2 “Digital Output
Level Relative to the Analog Input
Level” for details.
Selects an audio application for
AES and SDI AUDIO outputs.
PROFESSIONAL: Optimized for
professional use.
CONSUMER: Optimized for
consumer use.
Selects an audio word length for
AES and SDI AUDIO outputs.
6-11-3. AUDIO ERR SENSE
A U D I O E R R S E N S E
C H S T A T U S : S R C B Y P A S S
V A L I D I T Y : S R C B Y P A S S
FS1-1/2 – FS1-15/16
FS2-1/2 – FS2-15/16
AES 1/2 - AES 7/8
Selects a stereo channel pair for which to
enable Audio Error SENSE.
Selects audio error sensor mode for each
stereo channel pair of SDI and AES input
audio signals whose NON-PCM channel
status flag is 1.
*1
SRC BYPASS: Treats audio signals as
NON-PCM. By-passes audio signals
through SRC
*2
, and selects audio clock
input in the NON-PCM signal channel for
SDI AUDIO CLOCK.
*3
PCM: Treats audio signals as PCM
(standard audio signal). By-passes audio
signals through SRC
*2
, and selects
REFERENCE for SDI AUDIO CLOCK.
*3
MUTE: Treats audio signals as mute
signals.
Selects audio error sensor mode for each
stereo channel pair of SDI and AES input
audio signals whose channel status
Validity Bit flag is 1.
*1
SRC BYPASS: Treats audio signals as
NON-PCM. By-passes audio signals
through SRC
*2
, and selects audio clock
input in the NON-PCM signal channel for
SDI AUDIO CLOCK.
*3
PCM: Treats audio signals as PCM
(standard audio signal). By-passes audio
signals through SRC
*2
, and selects
REFERENCE for SDI AUDIO CLOCK.
*3
MUTE: Treats audio signals as mute
signals.
To Next Page
