18. About SNMP (Simple Network Management Protocol)
The FA-9520 can be remotely monitored and some of its settings can be remotely changed using
the SNMPv2C protocol. Some menu items can also be set via the network. MIB (Management
Information Base) is required for the monitoring and can be downloaded (see section 9-6-3
"Downloading a MIB File"). See section 9-8-3 "SNMP SETTING" for details about the SNMP
network settings.
○: Available
-: Unavailable
Object group
Front TITLE
Item name
Settings
Object name in MIB file
OID
Type
Read
(Get)
Write
(Set)
OID: 1.3.6.1.4.1.20175.1.307.1. (Unit info)
Unit info
－
Product Name
Model name
fa952ProductName
1
OCTET STRING
○
-
－
Product Code
Product code
fa952ProductCode
2
INTEGER
○
-
－
Unit Name
Unit name
fa952UnitName
3
OCTET STRING
○
-
－
Serial No.
Serial number
fa952SerialNumber
4
INTEGER
○
-
Unit Ver.
Soft
Software version
fa952SoftVersion
11
OCTET STRING
○
-
FPGA1 Ver
FPGA1version
fa952FPGA1Version
12
OCTET STRING
○
-
FPGA2 Ver
FPGA2 version
fa952FPGA2Version
13
OCTET STRING
○
-
FPGA3 Ver
FPGA3 version
fa952FPGA3Version
14
OCTET STRING
○
-
OID:1.3.6.1.4.1.20175.1.307.1.100. (Software option)
Soft Option
SOFT OPTION1/2
FA-95SCNV
0: notInstalled
1: installed
fa952ScnvOption
1
INTEGER
○
-
FA-95AVO
0: notInstalled
1: installed
fa952AvoOption
2
INTEGER
○
-
FA-95-3G
0: notInstalled
1: installed
fa952-3GOption
3
INTEGER
○
-
FA-95CO
0: notInstalled
1: installed
fa952CoOption
4
INTEGER
○
-
FA-95LG
0: notInstalled
1: installed
fa952LGOption
5
INTEGER
○
-
OID:1.3.6.1.4.1.20175.1.307.1.200.1 (Option Slot A)
OPTION Slot A
OPTION A Ver
Name
0: notInstalled
1: FA-95AIO
4: FA-95DE-E
5: FA-95D-D
11: FA-95DACBL
12: Unknown
15:FA-95ALA
fa952SlotTypeA
1
INTEGER
○
-
FPGA1 Ver
SlotA FPGA1 version
fa952FPGA1VerSlotA
2
OCTET STRING(5|13)
○
-
FPGA2 Ver
SlotA FPGA2 version
fa952FPGA2VerSlotA
3
OCTET STRING(5|13)
○
-
SOFT Ver
SlotA Software version
fa952CPUVerSlotA
4
OCTET STRING(5|13)
○
-
OID:1.3.6.1.4.1.20175.1.307.1.200.2 (Option Slot B)
OPTION Slot B
OPTION B Ver
Name
0: notInstalled
1: FA-95AIO
4: FA-95DE-E
5: FA-95D-D
11: FA-95DACBL
12: Unknown
15:FA-95ALA
fa952SlotTypeB
1
INTEGER
○
-
FPGA1 Ver
SlotB FPGA1 version
fa952FPGA1VerSlotB
2
OCTET STRING(5|13)
○
-
FPGA2 Ver
SlotB FPGA2 version
fa952FPGA2VerSlotB
3
OCTET STRING(5|13)
○
-
SOFT Ver
SlotB Software version
fa952CPUVerSlotB
4
OCTET STRING(5|13)
○
-
Object group
Front TITLE
Item name
Settings
Object name in MIB file
OID
Type
Read
(Get)
Write
(Set)
OID: 1.3.6.1.4.1.20175.1.301.2.1.1. (FS1 VIDEO PROCESS)
VIDEO
PROCESS
VIDEO PROCESS
AMPLIFER
FS1 VIDEO LEVEL
0.0 to 200.0%
fa952FS1VideoLevel
1
INTEGER
○
○
FS1 CHROMA LEVEL
0.0 to 200.0%
fa952FS1ChromaLevel
2
INTEGER
○
○
FS1 SETUP/BLACK
-20.0 to 100.0%
fa952FS1SetupBlack
3
INTEGER
○
○
FS1 HUE
-179.8 to 180.0% (Step:0.2%)
fa952FS1Hue
4
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.2.1.2. (FS2 VIDEO PROCESS)
VIDEO
PROCESS
VIDEO PROCESS
AMPLIFER
FS2 VIDEO LEVEL
0.0 to 200.0%
fa952FS2VideoLevel
1
INTEGER
○
○
FS2 CHROMA LEVEL
0.0 to 200.0%
fa952FS2ChromaLevel
2
INTEGER
○
○
FS2 SETUP/BLACK
-20.0 to 100.0%
fa952FS2SetupBlack
3
INTEGER
○
○
FS2 HUE
-179.8 to 180.0% (Step:0.2%)
fa952FS2Hue
4
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.307.2.2. (Input Video Signal Settings)
INPUT SEL
VIDEO IN SETTING
FS1 Input Select
0: SDI1
1: SDI2
2: Composite
3: OpA
4: OpB
fa952FS1VideoInputSelect
1
INTEGER
○
○
FS1Video Loss Mode
If no signal is present:
0: Back Color
1: Auto Freeze
2: Color Bar
3: Output Disable
fa952FS1VideoLossMode
2
INTEGER
○
○
FS2 Input Select
0: SDI1
1: SDI
2: Composite
3: OpA
4: OpB
fa952FS2VideoInputSelect
3
INTEGER
○
○
FS2Video Loss Mode
If no signal is present:
0: Back Color
1: Auto Freeze
2: Color Bar
3: Output Disable
fa952FS2VideoLossMode
4
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.307.2.3 (Output Video Signal Settings)
OUT SEL
OUTPUT ASSIGN
SDI1/2
0: FS1
1: FS2
fa952OutSDI1-2Sel
1
INTEGER
○
○
SDI3/4
0: FS1
1: FS2
fa952OutSDI3-4Sel
2
INTEGER
○
○
COMPOSITE
0: FS1
1: FS2
fa952OutCompositeSel
3
INTEGER
○
○
