FOR-A FA-9520 - Anc Detect Line; Anc Detect Sel

59
5-6-3. ANC DETECT LINE
Allows you to select a line to detect ancillary RP186 VI or BT1119-2 WSS data in input signals.
 For RP186 VI
A N C D E T E C T L I N E
30
ANC ： R P 1 8 6 V I
FORMAT： 525/60
FIELD1： 1 4 L I N E
FIELD2： 2 7 7 L I N E
Parameter
Default
Setting range
Description
ANC
RP186 VI
RP186 VI
BT1119 WSS
Selects an ancillary data
standard.
FORMAT
525/60
525/60
625/50
Selects the input signal format.
FIELD1
14 LINE (525/60)
19 LINE (625/50)
12-19 LINE (525/60)
8-22 LINE (625/50)
Selects a line to detect ancillary
data in field 1.
FIELD2
277 LINE (525/60)
324 LINE (625/50)
275-282 LINE (525/60)
321-335 LINE (625/50)
Selects a line to detect ancillary
data in field 2.
 For BT1119 WSS
A N C D E T E C T L I N E
30
ANC ： B T 1 1 1 9 W S S
FORMAT： 625/50
FIELD1： 2 3 L I N E
Parameter
Default
Setting range
Description
ANC
RP186 VI
RP186 VI
BT1119 WSS
Selects an ancillary data
standard.
FORMAT
625/60
625/50
Selects the input video format.
FIELD1
23LINE
8-23 LINE
Selects a line to detect ancillary
data in field 1.
5-6-4. ANC DETECT SEL
A N C D E T E C T S E L
31
C A P T I O N : C E A 6 0 8 C C
A F D : S 2 0 1 6 - 3AFD
Parameter
Default
Setting range
Description
CAPTION
*1
CEA608 CC
CEA608 CC
S334-1 CC
Select CEA608 CC to process closed
caption data in the luminance signal (Y) of
525/60 system.
Select S334-1 CC to process closed
caption data in ancillary data space of SDI
signal.
AFD
S2016-3 AFD
S2016-3 AFD
RP186 VI
BT1119 WSS
Selects a type of AFD data to be detected
for SD input signals.
*1 Be sure to set to CEA608 CC when processing closed caption data in 525/60 composite
signals. Otherwise the caption data will not be detected.
