5-10-22. ANC1 IN STATUS 1-2
D I D / S D I D : * * / * *
Displays the status of ancillary data packets in an FS1/FS2 input SDI signals.
Displays the detected DID and SDID of the ancillary data in hexadecimal format, such as
DID/SDID: 15/30, if they are different from that of supported formats.
Displays the ancillary data name, such as S334-1CDP(708), if the DID and SDID of the
ancillary data match that of supported formats.
See section 19. “FA-9520 Ancillary Data Packet Name List” for details on ancillary data
names, and DID and SDID of formats.
The status of up to 8 ancillary data can be displayed.
5-10-23. ANC OUT
C E A 6 0 8 : P R E S E N T L : 2 1
VI:P R E S E N T L : 1 4 / 2 7 7
Displays the status of CEA608, WSS, and VI ancillary data inserted into luminance signal of
FS1/FS2 output.
The line number in which the ancillary data is in is displayed.
Displays PRESENT if ancillary data is inserted. Displays ABSENT if no ancillary data is
inserted. If ANC MODE is set to H/V ANC, the state of the V ANC setting (PASS or BLANK)
will be displayed. In such case, no line number will be displayed. (See section 5-9-6 ANC SET
for details on ANC MODE and V ANC setting.)
5-10-24. S2016 OUT
Displays whether the S2016-3 ancillary data is inserted into FS1/FS2 output video signals.
When no S2016-3 is in the FS1 output video signal
If ANC MODE in 5-9-6 ANC SET is set to H/V ANC, the state of the V ANC setting (PASS or
BLANK) is displayed.
When S2016-3 is in the FS1 output video signal
D : 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
AFD: Active Format Description is displayed in hexadecimal format.
AR: Aspect Ratio is displayed in binary format (0=4:3, 1=16:9)
The detected AFD type is shown on the third row.
D: Detected Data1-8 are displayed in hexadecimal format.
See section 20-6“AFD Code Abbreviations” for details on AFD types.
