FOR-A FA-9520 - Anc Embed Line

65
5-7-5. ANC EMBED LINE
Allows you to select a line of SDI signal ancillary data space to insert closed caption data.
A N C E M B E D L I NE
38
A N C : C E A 6 0 8 C C
F O R M A T : 5 2 5 / 6 0
F I E L D 1 : 2 1 ( 2 8 4 ) L I N E
Parameter
Default
Setting range
Description
ANC
CEA608 CC
CEA608 CC
S334-1 CC SD
CEA708 CC HD
S2016-3 AFD
RP186 VI
BT1119 WSS
Selects a type of ancillary data to insert.
FORMAT
-
*1
Selects a video format compatible with the
ancillary data selected under ANC. Only
compatible Video formats will be displayed.
LINE
FIELD1
-
*1
Selects a line in ancillary data space into
which ancillary data is inserted. A line can be
selected for different ANC and FORMAT
selections separately.
If ANC is set to RP186 VI, this parameter
allows you to select a line for FIELD 1. Lines
can be selected for fields 1 and 2
respectively.
FIELD2
-
*1
If ANC is set to RP186 VI, this parameter
allows you to select a line for FIELD 2. Lines
can be selected for fields 1 and 2
respectively.
* Settings can be set for FS1 and FS2, respectively.
*1 The setting range varies according to the ancillary data type and video format.
Ancillary data type
FORMAT
LINE
Default
ANC:CEA 608 CC
525/60
FIELD1: 21(284) fixed
*1
ANC:S334-1 CC SD
525/60
FIELD1:12(275) to 19(282)
*1
FIELD1:12(275)
*1
ANC:CEA708 CC HD
1080i
LINE 9 to 20
LINE 9
720p
LINE 9 to 25
LINE 9
ANC:S2016-3 AFD
525/60
FIELD1:12(275) to 19(282)
*1
FIELD1:12(275)
*1
625/50
FIELD1:8(321) to 22(335)
*1
FIELD1:8(321)
*1
1080i/PsF
LINE 9 to 20
LINE 9
720p
LINE 9 to 25
LINE 9
1080p/(3G)
LINE 9 to 41
LINE 9
ANC:RP186 VI
525/60
FIELD1: 12 to 19
FIELD1: 14
FIELD2: 275 to 282
FIELD2: 277
625/50
FIELD1: 8 to 22
FIELD1: 11
FIELD2: 321 to 335
FIELD2: 324
ANC:BT1119 WSS
625/50
FIELD1: 8 to 23
FIELD1: 23
*1 Field2 line number displayed in parentheses.

If CEA608 or S334-1 CC closed caption data is detected in the input signal, and
the FS1 and/or FS2 converter output signal format(s) is/are 1080/59i or
720/59p, the detected closed caption data will be automatically converted to
CEA708. However, if CEA708 closed caption insertion is disabled, the data will
not be inserted.
If FS1 and/or FS2 converter output format(s) is/are 1080/PsF or 1080/59p, the
CEA708 closed caption data insertion will be automatically terminated.
