5-4-2-1. About Scene Cut Detection and Frame Delay Settings
To properly perform AVO scene cut detection and adjustment, the FRAME DELAY must
be set in the setting range according to the menu settings (5-9-1 “FS MODE SET” menu)
as shown in the table below.
FRAME DELAY Setting Range Chart
*1
SYNCHRO
*2
Setting Range per Input Video Format
525/60i
625/50i
1080/59i
1080/50i
720/59p/50p
1080/59p,50p
1080/23PsF, 24PsF
FRAME
1 to 8 FRAME
2 to 8 FRAME
LINE/AVDL
Cannot be set
Cannot be set
INPUT
2 to 8 FRAME
3 to 8 FRAME
*1 FS mode settings under SYNCRO in section 5-9-1 “FS MODE SET”
*2 The current input video format can be verified in the VIDEO IN STATUS menu
(Sec. 5-10-2) for each input selected in the FS INPUT SELECT menu (Sec. 5-6-1).
IMPORTANT
Adjust the audio delay as required in the AUDIO DELAY Settings menu (Sec. 6-6) to
account for any additional video signal delay produced by changing FRAME DELAY.
