5-7-3. AIO B ASSIGN
Allows you to assign video signals to output from video output connectors on the FA-95AIO in
slot B.
A I O B A S S I G N
35
A S S I G N : F S 1
M O D E : Y P b P r S M P T E
Parameter
Default
Setting range
Description
ASSIGN
FS1
FS1
FS2
Selects either FS1 or FS2 signal to
be output from the video output
connector on the FA-95AIO in slot
B.
MODE
YPbPr SMPTE
YPbPr SMPTE
YPbPr BETACAM
RGB
Y/C
Selects the operation mode for
output video signals from the
FA-95AIO installed in slot B.
* This menu does not appear if there is no FA-95AIO installed in slot B.
* The FA-95AIO connector outputs a black video if the output signal from the selected FS1
or FS2 is 1080p and MODE is set to YPbPr or RGB. See the below YPbPr/RGB Output
Format table for details.
* The FA-95AIO connector outputs a black video if the output signal from the selected FS1
or FS2 is an HD signal and MODE is set to Y/C. See the below Y/C Output Format table for
details.
YPbPr/RGB Output Format
FS1 or 2 output signal
FA-95AIO YPbPr/RGB
output signal
525/60
525/60 signal in FS 1 or 2
625/50
625/50 signal in FS 1 or 2
1080/59i
1080/59i signal in FS 1 or 2
1080/50i
1080/50i signal in FS 1 or 2
1080/24PsF
1080/24PsF signal in FS 1 or 2
1080/23.98PsF
1080/23.98PsF signal in FS 1 or 2
720/59p
720/59p signal in FS 1 or 2
720/50p
720/50p signal in FS 1 or 2
1080/59p
1080/59i black video
1080/50p
1080/50i black video
Y/C Output format
FS 1 or 2 output signal
Y/C output signal
525/60
525/60 signal in FS 1 or 2
625/50
625/50 signal in FS 1 or 2
1080/59i
525/60 BB signal
1080/50i
625/50 BB signal
1080/24PsF
625/50 BB signal
1080/23.98PsF
525/60 BB signal
720/59p
525/60 BB signal
720/50p
625/50 BB signal
1080/59p
525/60 BB signal
1080/50p
625/50 BB signal
