5-10-14. SDI 1/2 OUT AUDIO
S D I 1 / 2 O U T A U D I O
5 7 1
C H 1 : P C M
C H 2 : P C M
C H 3 : P C M
C H 4 : P C M
S D I 1 / 2 O U T A U D I O
5 7 2
C H 5 : P C M
C H 6 : P C M
C H 7 : P C M
C H 8 : P C M
S D I 1 / 2 O U T A U D I O
5 7 3
C H 9 : P C M
C H 1 0 : P C M
C H 1 1 : P C M
C H 1 2 : P C M
S D I 1 / 2 O U T A U D I O
5 7 4
C H 1 3 : P C M
C H 1 4 : P C M
C H 1 5 : P C M
C H 1 6 : P C M
Parameter
Display
Description
CH1 - CH16
PCM
SILENCE
NON-PCM
UNKNOWN
BLANK
BY-PASS
Displays the status of audio signal channels CH1
through CH16 of the SDI 1/2 output.
PCM: Normal audio signal
SILENCE: Mute signal
NON-PCM: Compressed audio data such as AC3
UNKNOWN: Unidentifiable
BLANK: No audio signal embedding
BY-PASS: By-passed through
Menu button
STATUS
OTHER
